*Specifications are subject to change. To be used as a guide only.
Transmission Details: Electro Shift
Payload: 3500 kg
Tare: 4635 kg
Engine: Xinchai A498BT1
Horsepower: 49 hp
Fuel Type: Diesel
Rated Capacity: 3500kg
Load Center: 500mm
Mast Tilt: 6/120
Min Turning Radius: 2530mm
Min Intersecting Aisle: 42250mm
Max Traveling Speed (load/unload): 18.5/20 km/h
Max Lifting Speed (load/unload): 400/420 mm/s
Max Gradient: 20%Self Weight: 4635kg
S/P Tread (front/rear): 1030/980mm
Rated Power: 36.8kw
STD Max Lifting Height: 3000mm
STD Mast Lowered Height: 2132mm
Free Lifting Height: 170mm
Overhead Guard Height: 2150mm
Overall Length (with fork): 3898mm
Axle Distance: 1750mm
Front Overhang: 498mm
Rear Overhang: 580mm
STD Fork size (L5xWxT): 1220x125x50mm
Min Ground Clearance Frame: 165mm
Min Ground Clearance Mast: 132mm
Overall Width: 1250mm
